Home // Produkte // Palettier-module // Highrunner HR14 Palletizer

Highrunner HR14 Palletizer

High-Speed Confectionery Palletizing

Der Highrunner HR14 palettiert Kartons mit flowverpackten Süßwaren und Snacks.

Angebot anfordern

Beschreibung
Spezifikationen
Konfigurationen
Downloads

Qimarox HR14 Candy (flow wrapped) – High-Speed Confectionery Palletizing

The HR14 snack palletizer is specifically designed for palletizing flow wrapped candy and snack cartons. This high‑performance palletizer combines speed, accuracy and a compact footprint, making it ideal for demanding snack production lines.

Whether you run single-flavor lines or promotional mix packs, the HR14 delivers reliable, flexible automation perfectly tailored to the high demands of candy production.

Built for High-Volume Candy & Snack Production

Candy producers face increasing pressure for automation and efficiency. The HR14 palletizer supports:

  • Rapid changeovers for different carton types

  • Recipe management for custom stacking patterns

  • Seamless integration with case packers and pallet wrappers

  • Minimal maintenance and high uptime

Whether you produce single-flavor cartons or promotional variety packs, the HR14 Candy Palletizer is a future-proof solution.

Benefits of the HR14 Palletizer for Candy (flow wrapped)

  • Compact design for easy integration
  • High-speed operation (up to 60 cartons per minute)
  • Gentle handling of lightweight and easily deformable products
  • Flexible stacking patterns
  • Ideal for mixed or single-product pallet loads
  • Reliable 24/7 operation
  • Flawless Stacking Smart layer formation ensures perfectly stable, transport-ready pallets every time
  • Cost & Labor Efficiency: Drastically reduces manual labor, product damage, waste, and rework
  • Gentle & High-Speed: high throughput with ultra-gentle handling to protect lightweight, easily deformable packaging

Discover the Qimarox Advantage

The HR14 palletizer for Candy (flow wrapped) snacks

is designed to grow with your production. Backed by Qimarox’s proven engineering and support, it ensures consistent pallet quality, operator safety, and long-term value.

Why choose Qimarox?

Qimarox is a leading manufacturer of components for material handling systems. As a manufacturer of palletisers and product lifts, Qimarox distinguishes itself with a contemporary vision and approach. Innovation, quality and added value are of paramount importance.

At Qimarox, we believe that the best solution starts with a conversation. Our specialists are ready to explore your application, challenges, and goals together with you. From initial advice and technical insights to full integration into your existing line — we’re committed to supporting you every step of the way.
Get inspired and take a look at our channels Vimeo - Youtube.

Would you like to learn more, discuss your project, or receive a no‑obligation quotation?

If you would like more information about our palletizing solutions, you can request a sales enquiry without any obligations. If you have any other questions please feel free to contact us!

🔗 Request a quotation easily through our online form
🔗 Or contact us for personalized advice

With the HR14 snack palletizer, manufacturers can efficiently palletize delicate flow wrapped candy products. Together, we’ll create a solution that truly works for your organization.

Entwickelt für die Anforderungen der Süßwarenproduktion

Die Highrunner HR14 Candy sorgt für gleichbleibend hohe Palettenqualität und unterstützt gemischte Lagen.

Geeignet für:

Süßwaren & Riegel:
Schokoriegel, Tafeln, Proteinriegel, Lollis, Kaugummi, Fruchtgummi, Lakritz.

Backwaren & Specials:
Kekse, Waffeln, Multipacks, Displays, saisonale Produkte.

Spezifikationen

  • Zuführhöhe: 600–1000 mm
  • Palettenhöhe: max. 2600 mm
  • Produktgröße: 150×125×75 – 400×300×400 mm
  • Leistung: 1320–1800 Produkte/Stunde
  • Lagen: max. 300/Stunde
  • Gewicht Produkt: 0.5–15 kg
  • Gewicht Lage: 25–180 kg
  • Palettengewicht: max. 1900 kg
Specifications Min. Max.
Infeed height at platform level (mm/inch) 600 / 24 1000 / 39
Pallet height (mm/inch)   2600 / 102.5
Product (LxBxH mm/inch) 150 x 125 x 75 / 6 x 5 x 3 400 x 300 x 400 / 16 x 12 x 16
Throughput(products/hour) 1320 1800
Throughput(layers/hour)   300
Product weight (kg/lbs)  0.5 / 1.1 15 / 33
Layer weight (kg/lbs)   25/55 180 / 400
Pallet weight (kg/lbs)   1900 / 4188


The Highrunner HR14 is build in the most optimal configuration for the Candy (flow wrapped) snacks industry.

Configurations will follow, contact us for more information.

Brochures

Icon

Flyer Palletizer HR14 Candy (flow wrapped) - EU metric

1 Datei(en) 1.14 MB

Download

Icon

Flyer Palletizer HR14 Candy (flow wrapped) - US imperial

1 Datei(en) 1.14 MB

Download


Dieses Produkt ist durch ein oder mehrere Patente geschützt. Weitere Informationen finden Sie unter hrpatents.qimarox.com/ .
